Scotch
?
Filament Tape
890C
3
Technical Data
Product Description
June, 2009
Scotch ? Filament Tape 890C is a high performance black packaging tape reinforced
with continuous glass yarn filaments which give the tape very high tensile strength.
The black 3M? Scotchpar? backing provides outdoor weathering, abrasion,
moisture, and scuff resistance. The adhesive is an aggressive packaging adhesive
specifically formulated to provide balanced performance, having both high adhesion
and long term holding power.
Construction
Backing
Black 3M?
Adhesive
Pressure sensitive
Reinforcement
Glass yarn
Backing Color
Black
Scotchpar? film
rubber resin
Typical Physical
Properties
Note: The following technical information and data should be considered representative
or typical only, and should not be used for specification purposes.
ASTM Test Method
Adhesion to Steel:
Tensile Strength:
Elongation at Break:
Total Thickness:
70 oz./in. width (77 N/100 mm width)
600 lbs./in. width (10,500 N/100 mm width)
3%
8.0 mil (0.202 mm)
D-3330
D-3759
D-3759
D-3652
Features
? Meets ASTM D5330, Type IV
(replaces PPP-T-97E).
? Protects tape from sunlight and ultra
violet rays.
? Good handling.
? Printable by the print seal process.
? High shear strength.
? Good initial adhesion.
? Excellent aging before and after
application.
? Excellent protection of filaments and
adhesive to provide longer package life.
? Maximizes package performance when
exposed to outdoor and humid
environments.
? Saves time through ease of dispensing
and handling versus glue and strapping.
? Low unit cost on applications where high
tensile strength is main requirement by
using less tape.
